1960s? Monarch Hy Lo Jack Hydraulic unit Brochure

• CATEGORIES: Advertising & Brochures, Features This site contains affiliate links for which I may be compensated.

UPDATE: **SOLD** Was on eBay.

This indicates these systems were designed for dump trucks, jeep trucks, scouts, and probably others.

“Here is a vintage Monarch Hydraulic power Controls for you snowplow, circa late 1950s.
Includes battery operated and fan belt driven models.
The brochure has models, HEP Dyna-Might, and the TUH or Hy-Lo-Jack.
On the back page is the Hy-Lo for Jeep model operates off fan-belt of Willys Jeep, CJ and 226
Also the model H-SC Hydraulic control fro the new International Scout.
Also HFC for Jeep, Monarch Controls for the Forward-Control Jeep.
There are also two other sheets.
One sheet show the break down of the UHT-JA (Hy-Lo-Jeep), parts list, parts price on the backside.
The other sheet is an photo showing the Hy-Lo-Jack Type UHT-J and TUH cut in half, with parts labeled.”

1960s-monarch-hy-lo-jack-hydraulic-snowplow-brochure2

1960s-monarch-hy-lo-jack-hydraulic-snowplow-brochure3

1960s-monarch-hy-lo-jack-hydraulic-snowplow-brochure4

1960s-monarch-hy-lo-jack-hydraulic-snowplow-brochure5



2 Comments on “1960s? Monarch Hy Lo Jack Hydraulic unit Brochure

  1. Bob

    This is pretty similar to the one I sent you not long ago. I just picked up a hy lo jack off ebay for a good price. The seller listed it as a “hi lo” instead of “hy lo”. It’ll fit the bill nicely for what I’m doing with it.

  2. Brian M.

    Hi, I have one of these pumps that I’m going to use for a plow setup on my 84 CJ7. I was just wondering what you run in it for fluid. I know it says to use SAE 10 oil, but the current system is running ATF. Any input on this would be greatly appreciated. Thanks!
    Brian
    Derry, NH
