Biscuit on its way home

Lost biscuit finally arrived in Prosser, though The Jeep is a shadow of its former self. The original 3.8L V-6 was burning oil badly out of cylinder one, so while replacing the engine I also replaced the transmission, switching from an TH350 automatic to a T-18 with a low first. But, I could never find the time to complete that transition. Engine placement, driveline angle, and  header angles seemed to fight me the entire transition. However, now that Biscuit is here, I’ll eventually have some time to devote to it (first, the race jeep’s seat will get adjusted for my height, then I will deal with Patterson’s generator and with the brake-clutch pedals, then Lost Biscuit).

To get Biscuit home, first I had to install a winch onto the tilt bed. After thinking through various ideas, I came up with a trial system that secured a winch frame to the tilt deck, but used a vertical angle against the from of the tilt deck as added leverage for the winch.

Here are some of the pieces I started with:

This shows the underside of the tilt deck. The square tubing in the pic above this one was drilled and bolted to the deck, with the bolts going through the wood and into angled pieces on either side of the hydraulic arm. I figured that was the least invasive way of mounting a winch (for now).

This shows the completed platform bolted onto the deck. Note how the front angle piece on the left sits down in front of the tilt bed. This allows the tilt bed to open and shut:
