Overdrive Differences

• CATEGORIES: Features, OD Other, OD Saturn/Warn This site contains affiliate links for which I may be compensated.

Will shared pics that show some of the differences between a Warn overdrive with a Husky overdrive. Regarding finding Husky parts, my best guess for parts would be Herm Tilford.

Will writes, “A little while back there was a discussion on the different overdrive units. There where several different units produced and maybe others but the ones I’ve seen are Warn, Dualmatic, Saturn, Husky and ATV overdrives that all looked similar. Saturn is a direct decedent of the Warn as Advance Adapters purchased the tooling from Warn to make the Saturn. I don’t know much about the Dualmatic or ATV except ATV is still produced as is Saturn.

Anyway I had mentioned that the Husky had a different angle to the planetary gears, Sun gear and bowl gear than Warn. These pictures show how the Warn had much more tooth angle than Husky and as such these parts do not interchange and Husky parts are near impossible to find.”

IMG_8652 IMG_8651 IMG_8650

[fb_button]

To Top

Warn Overdrive Inverness, FL **SOLD**

• CATEGORIES: OD Saturn/Warn This site contains affiliate links for which I may be compensated.

UPDATE: **SOLD** Was $150.

Mark just posted this a sellajeep.com. Its got one broken piece.

“from a 1959 cj5 t-18 transfer case. One small broken piece (see photos) gears and bearings in good condition. Located in central Florida.”

overdrive-fl1 overdrive-fl2 overdrive-fl3 overdrive-fl4

[fb_button]

To Top

Unusual Auxiliary Transmission … Can Anyone Identify It?

• CATEGORIES: Features, OD Other, OD Borg Warner/Rancho, OD Saturn/Warn This site contains affiliate links for which I may be compensated.

UPDATE: While still unidentified, we have learned thanks to the Dutch_Jeeper on the CJ-3A page that the auxiliary transmission is an “under-drive” rather than an overdrive. He pulled this out of his CJ-3A, then disassembled it.

You can learn more and see more pics here: https://cj3apage.com/Forum/index.php?topic=2318.msg19546#msg19546

auxiliary-transmission-underdrive01

auxiliary-transmission-underdrive02

auxiliary-transmission-underdrive06

==================

Originally Posted February 5, 2021: An owner of a CJ-2A posted onto Facebook these photos of an unusual auxiliary transmission. I only am aware of two that work between the T-90 and Dana 18 (the Warn and the Husky). Anyone recognize this?

IMG_1879 Continue reading

[fb_button]

To Top

Warn Auxiliary Transmission

• CATEGORIES: Advertising & Brochures, Documents, Features, OD Saturn/Warn This site contains affiliate links for which I may be compensated.

Originally Published November 03, 2019:

warn-auxilary-transmission-brochure1-lores warn-auxilary-transmission-brochure2-lores

===========================

Originally posted in September of 2018:
auxilary-warn-overdrive-installed

Blaine spotted a discussion at the Ford-Trucks.com forum on Auxiliary transmissions that included the rare Warn Auxiliary Overdrive. A user named “38 Coupe” shared a bunch of smaller Auxiliary transmission documents that included a Parts and Instruction manual for the Warn AO. So, here it is, along with some photos of a Warn unit that was for sale in April of 2015.

warn-auxiliarly-transmission-overdrive-instructions1

Continue reading

[fb_button]

To Top

NOS Warn Overdrive Santa Cruz, CA **SOLD**

• CATEGORIES: OD Saturn/Warn This site contains affiliate links for which I may be compensated.

UPDATE: **SOLD** Was $1000.

Looks like this one has been sitting in someone’s garage for a while.

“Warn Overdrive, 26 tooth 6 spline. New condition not a rebuilt unit, This was in a project Jeep I purchased that was never completed to run. Overdrive was mounted but never used, new condition but is many years old. Includes Overdrive, new gasket and seal set, new install lock and keeper set, shifter with floor plate and instructions. SOLD AS IS, buyer to be sure of correct application, $1000 cash only no checks, no trades.”

warn-overdrive4

warn-overdrive0 warn-overdrive1 warn-overdrive2 warn-overdrive3

[fb_button]

To Top

Warn Overdrive Catalog from the late 1960s (?)

• CATEGORIES: Advertising & Brochures, Books, Features, OD Saturn/Warn This site contains affiliate links for which I may be compensated.

UPDATE: This was originally posted in 2012, but it’s worth a repost.

Dad never had an overdrive in his jeep, but did have this catalog (No. 1842). I suspect he built a few of these for Al Carroll.

I’ve attached a few random pictures below, but the PDF link includes all the pages and is downloadable to your computer.

http://www.ewillys.com/pdf/Warn-Overdrive-Parts-Catalog.pdf

[fb_button]

To Top

1969 Buick 225/SM420/Dana 18/Warn OD Bakersfield, CA **Status Unknown**

• CATEGORIES: OD Saturn/Warn, Parts This site contains affiliate links for which I may be compensated.

UPDATE: **SOLD** Was $1600.

Seller is accepting offers.

buick225-od-sm420-1 buick225-od-sm420-2

“Hi all, I recently sold my willys jeep and the buyer didnt want the engine, trans, transfer case and Overdrive.
I am relisting these parts for sale.
1969 Buick/Jeep CJ 225 Odd fire V6 engine, fully rebuilt with $2200 dollars in receipts. Has both 2 and 4 Brl Intake. manifolds.Isky RV type cam. Engine has been properly stored and never fired up.
GM SM420 4 speed transmission rebuild by Herm the OD guy, compound low first gear, final drive 100 to 1
Novak Adapter to rebuilt Large shaft Dana 18 transfer case
New never used Warn OD unit from Herm the OD guy.
As above this was built for a willys but will adapt to any pre smog Jeep.
Open to trades. Make an Offer. Motivated to sell”
