Chris’ Jeep Parts on eBay

• CATEGORIES: Documents, Features This site contains affiliate links for which I may be compensated.

Chris has posted some jeep parts and items on eBay. Here’s a link to his items:

https://www.ebay.com/sch/elijah12012/m.html?_nkw=&_armrs=1&_ipg=&_from=

One of the more interesting items is this jeep logo placement poster:

jeep-log-poster-placement jeep-log0-poster-placement2 jeep-log0-poster-placement3


To Top

1962-1973 NOS Parts Catalog on eBay

• CATEGORIES: Documents, Features This site contains affiliate links for which I may be compensated.

This contains a variety of parts information, including “models 67/71 Jeepster, 62/71 Universal, 72 & 73 Commando CJ DJ 5 6 (various open body, fire engine, gas, diesel, convertible, roadster, station wagon, full cab, pickup, half cab, etc.” So, it might have some interesting info.

View all the information on eBay

“Item Description: Original Jeep Dealer Parts Catalog, 1962 – 1973, with original reddish heavy 3 metal post binder “American Motors / Jeep Parts Catalog”. Covers: models 67/71 Jeepster, 62/71 Universal, 72 & 73 Commando CJ DJ 5 6 (various open body, fire engine, gas, diesel, convertible, roadster, station wagon, full cab, pickup, half cab, etc.). Illustration and Text, parts only, no price list. About 4″ thick. September 1974 print date. Good for looking up NOS part numbers. Good condition, light wear, metal and edge darkening, scuff, small plastic tab on binding edge 1″ top gone. Item has reddish covers, pages are whitish color (camera error kept trying to correct color to reddish background). Inside printing all good condition.”

1960s-parts-catalog1

1960s-parts-catalog2

1960s-parts-catalog3

1960s-parts-catalog4


To Top

British Airborne WWII Jeep Conversion Blueprints **SOLD**

• CATEGORIES: Documents, Features This site contains affiliate links for which I may be compensated.

UPDATE: **SOLD (fast)** These were on eBay.

These are copies, but are priced as such. I’m sure they would be interesting to someone. They ship from GB.

“Over the years my interest in British ww2 airborne troops has been high, and amongst my collection I converted my jeep to full glider-borne specifications
The drawings I used were from originals which I copied and give full details on the placing of parts and how to make them, with measurements and good details
They’re on A3 paper and come as 10x sheets. They cover:
Pannier carrier
Spare wheel carrier
Bonnet ammo carrier
Steering wheel quick release
Front bumper
Positioning of parts in the jeep
Jerry can carrier reposition
Radio aerial/battery carrier base
A frame for towing”

blueprints-airborne-jeep-conversion1

blueprints-airborne-jeep-conversion2

blueprints-airborne-jeep-conversion3


To Top

National Archives Early Jeep Testing

• CATEGORIES: Documents, Features, Old Images This site contains affiliate links for which I may be compensated.
1942-05-27-digging-potatoes

Early look at a jeep being tested for farm work in 1942.

For you history geeks out there like me, the national archives operates a blog called the “Text Message” where archivists can share a bit of the massive information troves that make up the National Archives, complete with references. Unfortunately, in this case, the references have not been posted online, but at least researchers can now use the breadcrumbs from the post to help track down the relevant documents if need be.

One particular post, written by archivist Joseph Gillette in 2019, highlights the early tests of the jeep for farm work. One bit of info I found interesting highlights the War Department’s dedication to its troops. When Willys-Overland volunteered to send some new jeeps to the Ag Department for farm tests, the War Department responded it could not spare the new jeeps as soldiers desperately needed them, but it would authorize the use of used ones in running condition.

Read the entire blog post here: https://text-message.blogs.archives.gov/2019/04/23/it-will-do-everything-except-climb-a-tree/#_ftnref2

Here are some additional images from the post:

1942-05-27-hauling-apples 1942-05-27-papers-on-jeep-as-farm-tool


To Top

1993 The Total Performance Jeep Engine Book

• CATEGORIES: Documents, Features This site contains affiliate links for which I may be compensated.

I thought I would win this auction, but I didn’t bid quite high enough. It looks like an interesting book. The guy who sold it on eBay said he used it to build a “bullet proof” AMC 360 engine. This book was printed in 1993.

Here are the pics posted on the auction:

1993-total-performance-jeep-engine-book1 1993-total-performance-jeep-engine-book2 1993-total-performance-jeep-engine-book3 1993-total-performance-jeep-engine-book4 1993-total-performance-jeep-engine-book5


To Top

June 1946 Surplus Jeep Sales w/ Serial Numbers

• CATEGORIES: Documents, Features, Old News Articles • TAGS: This site contains affiliate links for which I may be compensated.

UPDATE: I’ve added high-resolution examples of each of these articles. You can download the zipped file here: jeep-serial-numbers-sale-in-hawaii.zip

This is a cool find. It announces the first sale of jeeps to veterans in Hawaii for personal use (as well as business). There have got to be a few jeeps still around that originated at this surplus sale. This was published in the June 01, 1946, issue of the Hawaii Tribune-Herald (page 4). I’ve divided up the list into multiple images. At the bottom of this post is a link for the entire clipping.

1946-06-01-hawaii-tribune-herald-surplus-jeep-serial-number0

First of three lists:1946-06-01-hawaii-tribune-herald-surplus-jeep-serial-number1

Continue reading


To Top

Willys-Overland Motors Mechanics Agreement

• CATEGORIES: Documents, Features This site contains affiliate links for which I may be compensated.

UPDATE: This was on eBay. These are some unusual documents. I never did obtain copies of these agreements.

“VINTAGE TO WORLD WAR 2 ERA
WILLY’S JEEP OVERLAND EPHEMERA
2 DUES BOOKLETS WITH STAMPS AND NOTATIONS
CONSTITUTION AND BY-LAWS

GOOD CONDITION FOR THE AGE
THESE ITEMS NOT OFTEN FOUND ANY LONGER”

willys-overland-mechanic-society-documents2

willys-overland-mechanic-society-documents


To Top

1958 German CJ-3B Manual on eBay

• CATEGORIES: Documents, Features, International This site contains affiliate links for which I may be compensated.

This is the first German 3B manual that I’ve seen. I’m not sure how many of these re still out there.

View all the information on eBay

“Original Willys 1958 CJ-3B reprint in size A5
Original reprint of the Jeep Willys manual in original size A5: manual for the vehicle owner of the famous Willys Jeep.”

1958-cj3b-manual-german01

1958-cj3b-manual-german4

1958-cj3b-manual-german1

1958-cj3b-manual-german2

1958-cj3b-manual-german3

1958-cj3b-manual-german0




To Top

FC PTO Mechanical Drawings on eBay

• CATEGORIES: Documents, Features This site contains affiliate links for which I may be compensated.

There are three different auctions for FC-170-related PTO mechanical drawings.

  1. 1963 FC-170 PTO Drawings $29.95:
    Excellent Condition
    Mechanical Drawing
    ‘Jeep’ FC-170
    PTO INSTALLATION
    923931
    Measures about 21 ¼ x 11 inches and folds to8 ½ x 11 inchesfc170-pto-mechancial-drawings1 fc170-pto-mechancial-drawings2
  2. 1960 FC-150 PTO Drawings $39.95:Mechanical Drawing
    WILLYS MOTORS
    FC-150 P T O INSTALL
    This original Mechanical drawing measures about 21 ½ x 11 inches
    Dated 9-16-60
    fc150-pto-drawings1 fc150-pto-drawings2
  3. 1960 FC-170 PTO Drawings $39.95:
    “Mechanical Drawing
    WILLYS MOTORS
    FC-170 P T O INSTALL
    This original Mechanical drawing measures about 21 ½ x 11 inches
    Dated 9-16-60”
    1960-fc170-pto-drawings1 1960-fc170-pto-drawings2

To Top

July 1945 Press Release Photo #3

• CATEGORIES: Documents, Features, Old Images • TAGS: This site contains affiliate links for which I may be compensated.

This photo, marked as photo #3, shows prototype CJ-2 X59 at New Hudson. The caption discuses the Ginsu-like qualities of the jeep on the farm: It can mow, disk, rake, trash and probably slice and dice with the right attachments.

1945-07-willys-overland-press-kit-photo3-lores 1945-07-willys-overland-press-kit-photo3-caption-lores
